This ND-11 is a handy type densitometer (reflection density meter) that is most appropriate for color density management by reflectance for electronic apparatuses, precision instruments, metals and building material, etc
Measurements are easily made just by pressing a head softly at a sample.
Using target mark, you can focus on a measuring point.
In addition to the measurements of reflection density for visual feeling and yellowness density, this model is equipped with the function to measure reflectance that is also useful for gloss measurement.
Maximum 500 data pieces of measurement data can be saved into a built-in memory, and it is also possible to arbitrarily output a range of measurement data to your PC or printer.
This model is equipped with the function of average value measurement for maximum 9 points of measurement values. You can also make use of the data compensation function to get data compatibility with the ones obtained by your convensational instruments.
Dimensions
L 210mm x D 72mm x H 50mm
Weight
Approx. 530g (including battery)
Power supply
NiCd battery (4.8V, 800mAh),
Charged by AC adapter (9V, 500mA)
Light source
Halogen lamp
Measuring items
Reflection density , Reflectance
Measuring range
• Reflection density : 0.00D to 3.00D or more (values than 2.50D, however, will be rough indications) • Reflectance : 0.00D% to 100D%
Measuring aperture
3.0mmΦ (standard), 1.7mmΦ or 1.0mmΦ (to be selected)
Illumination & light receiving condition
0º : 45c
Data compensation function
Equipped : Higher compatibility with the data of your conventional instruments can be maintained using this function.
Averaging measurement
An avarage value of reflection density can be calculated by one-touch from 2 points to 9 points.
Memory of measurement data
Maximum 500 data pieces can be saved into a memory.
Measurement accuracy
• 3.0mmΦ : ±0.01D (for 0.2D or less)
(Visual feeling. Y density) • 1.7mmΦ : ±0.02D (for 1.0D or less)
(Visual feeling. Y density) • 1.0mmΦ : ±0.03D (for 1.0D or less)
(Visual feeling. Y density)
Option
• Add-in software for data transfer to Excel • RS-232C interface cable • Printer (PR-95) • NiCd battery for ND • Standard plate for accuracy control, etc.
