ND-12 is a handy type light-weight and compact densitometer (reflection density meter). Its operation is very easy and what you have to do is just fitting and pressing its target mark on a measuring spot. You can measure luminous reflection density, yellowness density, reflectance, etc. using this one unit. Measuring aperture is selectable from Φ1mm or Φ3mm depending on a sample size. This model will be a most suitable instrument for density management of printed matter and gloss evaluation of electronic components, lead frames, plated parts, etc.

Features

This is a handy type densitometer (reflection density meter) that is light-weight, compact and portable.

It can measure luminous reflection density, yellowness density, reflectance, etc. by this one unit.

Measurement is simple just by fitting and pressing a target mark on a measuring spot.

Depending on a sample size, you can select measuring aperture from Φ1mm or Φ3mm.

Various measuring functions are available for average value calculation, data compensation, etc.

500 pieces of measurement value data can be saved into the built-in memory.

An exclusive printer and data transfer software are available for use (in option).
